Analog Devices Inc. EVAL-AD5940BIOZ Evaluation Kit

Analog Devices Inc. EVAL-AD5940BIOZ Evaluation kit consists of the Arduino Uno form factor board integrated with EVAL-ADICUP3029 Arm® Cortex™-M3 microcontroller. This evaluation kit is designed for Body Impedance Analysis (BIA) and Electrodermal Activity (EDA). The AD5940BIOZ contains AD5940 for bio-impedance and the AD8233 for ECG measurements. This evaluation kit features custom micro USB-ECG snap connectors.

Specifications

  • Includes EVAL-ADICUP3029 Arm® Cortex™-M3 microcontroller based Arduino Uno form factor board
  • Consists of AD8233 for ECG measurements and AD5940 for bio-impedance
  • Designed for BIA and EDA
  • Contains custom micro USB-ECG snap connectors

Applications

  • Skin impedance
  • Body impedance
  • Battery impedance
  • Electrodermal activity
    • Electrocardiogram (ECG)

Additional Resource

Associated Product

Módulo frontal analógico AD5940/AD5941

Analog Devices Inc. Módulo frontal analógico AD5940/AD5941

Dispositivos AFE que tienen la capacidad de medir voltaje, corriente e impedancia con alta precisión.

Learn Moreacerca de Analog Devices Inc. Módulo frontal analógico AD5940/AD5941 View Productsrelacionado con Analog Devices Inc. Módulo frontal analógico AD5940/AD5941
Publicado: 2019-05-09 | Actualizado: 2022-03-10
